| Appearance Design |
| Color |
Orange/Black |
| Material |
PC |
| USB |
Type-C, USB 2.0 |
| Headphone Jack |
3.5mm |
| Expansion Connector |
uSmart Expansion Connector, supporting accessories related to uSmart series. |
| Card Slots |
3, 1 Nano-SIM+ 1 Nano-SIM+ 1 microSD |
| Keys |
Right: Power Button (Fingerprint)+Volume Button+Camera Key, Left: Custom Key |
| Size & Weight |
| Product Size |
173.4*83.35*18.3 mm |
| Product Weight |
406g |
| Package Size |
195.5*99.5*69.5 mm |
| Package Weight |
745g |
| Rugged |
| Certification |
IP68/IP69K/MIL-STD-810H |
| Splash, Water, and Dust Resistant |
Maximum depth of 2 meters up to 30 minutes |
| Drop resistance |
Up to 2M tall |
| Working Temperature |
-20℃ – 55 ℃ (-4℉ – 131℉) |
| Display |
| Screen Size |
5.93-inch |
| Screen Resolution |
720 x 1440 HD+ |
| Aspect Ratio |
18:9 |
| PPI |
272 |
| Color Depth |
8bit, 16.7M |
| Refresh Rate |
60Hz |
| Screen-to-Body Ratio |
75% |
| Multi-touch |
10 |
| Processor |
| CPU Model |
Unisoc T616 |
| Main frequency |
2.0GHz |
| CPU Core |
2x Arm Cortex-A75, 2.0G+6x Arm Cortex-A55, 1.8G |
| GPU |
Arm Mali-G57, 750MHz |
| RAM & Storage |
| RAM |
8GB LPDDR4X +8GB virtual RAM (The virtual RAM can be activated in Settings at your will. ) |
| Storage |
128GB, UFS2.2 |
| Max. Expansion Supported |
2TB |
| Rear Camera |
| Rear Camera Numbers |
2 |
| Main Rear Camera |
Pixel: 50MP |
| Details: SAMSUMG S5KJN1 CMOS sensor, 1.0μm, 6 piece lens, FOV 77.07°, ƒ/1.75 large aperture |
| Wide Angle Camera |
Pixel: / |
| Details: / |
| Macro Lens |
Pixel: 2MP |
| Details: OV02A10 CMOS sensor |
| Depth Sensor |
/ |
| Flash |
1 |
| Video Recording Resolution |
FHD(30fps), HD(30fps), SD(30fps) |
| Special Features |
Normal Mode, Night Mode, 50MP, Pro Mode, Macro Mode, Portrait, Panorama Mode, Time Lapse, Slow Motion, Intelligent Scanning |
| Front Camera |
| Pixel |
8MP |
| Details |
SAMSUMG S5K4H8YX13 CMOS sensor, 1.12μm, 4 piece lens, FOV 86.4°, ƒ/2.0 large aperture |
| Video Recording Resolution |
FHD(30fps), HD(30fps), SD(30fps) |
| Special Features |
Normal Mode, Portrait |
| Battery & Charging |
| Capacity |
9600mAh |
| Watt Hours Per Battery |
36.96 Wh |
| Battery Type |
lithium-ion polymer battery |
| Charging Details |
18W，9V/2A |
| Wireless Charge |
N/A |
| Standby Time |
528 Hours |
| Talk Time |
52 Hours |
| Network & Connectivity |
| Card Type |
Nano+Nano+microSD |
| Cellular |
4G/3G/2G |
| Band Details |
5G: N/A |
| 4G: FDD-LTE: B1/2/3/4/5/7/8/12/17/18/19/20/25/26/28A/28B/66 |
| 3G: WCDMA: B1/2/4/5/8 |
| 2G: GSM: B2/3/5/8 |
| Standby Mode |
Dual sim dual standby |
| VoNR |
N/A |
| VoLTE |
Support |
| WiFi |
2.4G/5G, 802.11 a/ac/b/g/n |
| Bluetooth Version |
BT5.0 |
| Navigation |
GPS/GLONASS/Beidou/Galileo/Digital Compass |
| Audio |
| Speaker Numbers |
1 |
| Speaker Model |
3600 |
| Speaker Power |
3.5W |
| Smart PA |
AW88394 |
| Loudness |
126dB |
| Special Features |
N/A |
| Security |
| Fingerprint ID |
Support |
| Face Unlock |
Support |
| System & Features |
| Android Version |
Android 13 |
| Pre-installed APP |
Google Assistant, Calculator, Google Calendar, Camera, Children Space, Chrome, Cleaning Assisant, Clock, Contacts, Google Drive, Files by Google, Find Device, FM Radio, Funny Sound, Game Booster, Gmail, Google, Google TV, Google Maps, Google Meet, Google Messages, Mobile Guardian, Outdoor Toolbox, Phone, Google Photos, Google Play Store, Safety, Service Center, Settings, Sound Recorder, Theme, Widget Box, Youtube, YT Music |
| Language |
Indonesian, Malay, Catalan, Czech, Danish, German, Estonian, English, Spanish, Filipino, French, Croatian, Italian, Latvian, Lithuanian, Hungarian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Finnish, Swedish, Vietnamese, Greek, Turkish, Bulgarian, Russian, Serb, Ukrainian, Armenian, Hebrew, Urdu, Arabic, Persian, Hindi, Bengali, Thai, Korean, Burmese, Japanese, Simplified Chinese, Traditional Chinese |
| Blinking Notification Light |
Support, red/green/blue light |
| Battery Status Light |
Support |
| Audio Format Supported |
MID/FLAC/MKA/MP3/M4A/AAC/AMR/OGG/MP2 |
| Video Format Supported |
FLV/MKV/AVI/3GP/MP4 |
| Image Format Supported |
GIF/JPEG/PNG/BMP |
| Text Format Supported |
TXT/HTML |
| FM Radio |
Support, headset-free FM radio |
| Cell Broadcast |
Support |
| Sensor |
Proximity Sensor, Light Sensor, Acceleration Sensor, Geomagnetic Sensor, Pedometer, NFC |
| Special Features |
| Underwater Camera |
Support |
| Gloves Mode |
Support |
| Digital Toolbox |
Compass, Gradienter, Flashlight, Hanging Painting, Height Meter, Magnifier, Alarm Bell, Plumb Bob, Protractor, Noise Test, Pedometer, Underwater Camera |
| OTG Function |
Support |
| NFC |
Support |
| Packing List |
Phone
AC Power Charger (100~240V /EU plug), 18W, 9V/2A
USB to Type-C Data Cable (100cm)
Protective Film (Pre-installed)
Tempered Glass Screen Protector
SIM Needle
Lanyard
Multi-language User Manual
Multi-function Instruction Card
Warranty Card
Charging Instruction Card
Safety Prompt Card
Accesories Ecosystem Brochure
Service Center Instructions |
| Product Certification |
CE, FCC, IP68, WEEE, ROHS.TAC |
